Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining

Model Number : 2-4 FLUTES

Brand Name : KEDEL

Place of Origin : Sichuan, China

MOQ : 10

Price : $1.70-2

Material : Tungsten Carbide

Grain Size : 0.6um

Shape : Ball

Coating : nACo4

Hardness : 55HRC

Helix Angle : 35°

Flute Count : 2-4

Cutting Diameter : 0.15-1.25mm

Flute Length : 2-8mm

Shank Diameter : 4mm

Overall Length : 50mm

Suitable Materials : CAST IRON, COPPER ALLOY, ORDINARY STEEL PARTS, CHISEL TOOL STEEL

Color : Slivery

Flute Type : Double blade-Four blade

Angle : 35°

Contact Now

Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining
Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining
Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining
Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining
Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining
Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining
parameter
value
Flutes
2-4
Chip Flute
2-4
Coating
nACo4
Shape
Ball
Angle
35°
HRC
60°
Tungsten Carbide End Mill with 2-8mm Flute Length, 4mm Shank Diameter, and 50mm Overall Length for Precision Machining

Number of Flutes
Cutting Diameter
Flute Length
Shank Diameter
Overall Length
d
l
D
L












Double blade
-
Four blade
0.15
2
4
50
0.2
2
4
50
0.25
2
4
50
0.3
2
4
50
0.35
3
4
50
0.4
2
4
50
0.5
2
4
50
0.75
6
4
50
1
6
4
50
1.25
8
4
50
0.15
2
4
50
0.2
2
4
50
0.25
2
4
50
0.3
2
4
50
0.35
3
4
50
0.4
2
4
50
0.5
2
4
50
0.75
6
4
50
1
6
4
50
1.25
8
4
50
